Pipe Floats

Advanced Design & Precision Manufactured for Robust Performance.

project

SUPERIOR has designed and manufactures an improved range of hose and pipe floats, suitable for all marine applications including dredging, mining, water treatment and aquaculture.

Rotomoulded using high impact polyethylene, the pipe floats are now available with a quick release strap, eliminating the time consuming process of bolting the floats together. Moulded locating pins for ease of installation and a convenient moulded hole in both ends allow for improved storage and security..

Also now available is the option of glass reinforced polyethylene bolts and nuts. Light weight yet remarkably strong, they offer a corrosion free and economical alternative to galvanised or stainless fittings. Internal diameters range from 10mm up to 630mm and are suitable for cable, hose and pipe. The floats can be foam filled if required and an extensive colour range is available, as is the optionof passive radar and light reflective stripes.

Specification

Available sizes :
10mm up to 130mm.
135mm. up to 225mm.
230mm. up to 355mm.
360mm. up to 630mm.
710mm. up to 1000mm.

Accessories

  • Quick release straps options
  • Stainless steel nuts and bolts

Features

  • Convenient storage/security holes
  • Locating pins for ease of installation
  • Optional passive radar and light reflective stripes
  • Heavy duty, high impact rotomoulded polyethylene floats
  • Extensive colour range and optional foam filled models available
  • Suitable for floating cables, pipes and hoses diameters from 10mm. to 630mm.
  • Quick release strap option saves time/money as bolts not essential
  • Used in many industries, mining, water treatment, aquaculture, dredging etc.
